The heating surface of the boiler is fully fused by argon-shielded welding and X-ray inspection, and the water pressure test is qualified.

2. Using the unique patented technology, the top of the furnace is equipped with a top coil, and the furnace tube is heated on both sides, which prolongs the residence time of the high-temperature flue gas in the furnace and improves the life of the boiler.
3. The chain grate realizes automatic coal removal and slag, which is convenient for operation.
4. Mechanical forced combustion, design special furnace arch, full combustion.
5. The running speed of the grate is controlled and displayed by the knob, which can be adjusted at any time according to the actual situation to ensure full combustion.
   •



   •



6. COAL OR BIOMASS FIRED THERMAL OIL BOILER




7.

8. Technical parameter





   Capacity	KW		1200	1400	2000	2400	3000	3500	4100
   	X10⁴Kcal/h		100	120	160	200	250	300	350
   Pressure (Mpa)			1.1
   Medium Max. temperature (℃)			320
   Circulating oil volume (m³/h)			100	100	160	180	200	200	250
   Boiler oil volume (m³)			1	1.1	1.9	2.2	2.38	3.1	3.4
   Efficiency (%)			76.46	77.7	78.08	78.08	78.47	78.5	79.2
   Connecting pipe diameter (DN)			150	150	150	150	200	200	200
   Boiler weight (kg)			17000	18000	25000	26100	34000	38600	40000
   Dimension (mm)		L	4710	4710	5821	5821	6834	6814	6814
   		W	2020	1930	2040	2040	2040	2500	2500
   		H	3600	3808	4040	4349	4487	4487	4846



9. Capacity	KW		4700	6000	7000	8200	9300	12000	13900
   	X10⁴Kcal/h		400	500	600	700	800	1000	1200
   Pressure (Mpa)			1.1
   Medium Max. temperature (℃)			320
   Circulating oil volume (m³/h)			250	300	340	400	520	600	800
   Boiler oil volume (m³)			3.8	4.6	7.5	10	11.2	12	13.5
   Efficiency (%)			79.5	79.5	79.1	79.5	79.7	81.1	79.1
   Connecting pipe diameter (DN)			200	200	250	250	250	300	350
   Boiler weight (kg)			45000	59000	70000	86500	95400	105000	113845
   Dimension (mm)		L	7214	8850	9070	10250	11300	11830	12330
   		W	2500	3040	3200	3200	3200	3320	3686
   		H	4874	5235	5287	5432	5372	6070	5991
